Image is for your reference only,please check specifications for details

CMP04FSZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC211096
Category:
Comparator, Analog Comparator IC
RoHS:
Lead free / RoHS Compliant
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES CMP04FSZ Analog Comparator, Quad, Precision, 4, 1.3µs, 3.3V to 36V, SOIC, 14Pins
Stock Locations:
Availability:
228 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 12.57

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The CMP04FSZ is a quad low power Precision Comparator comprises the CMP04. Performance highlights include a very low offset voltage, low output saturation voltage and high gain in a single-supply design. The input voltage range includes ground for single-supply operation and V- for split supplies. A low power supply current of 2mA, which is independent of supply voltage, makes this the preferred comparator for precision applications requiring minimal power consumption. Maximum logic interface flexibility is offered by the open-collector TTL output.
200V/mV High gain
Input voltage range includes ground
Low power consumption
1mV Maximum low offset voltage
Logic output compatible with TTL, DTL, ECL, MOS and CMOS
Directly replaces LM139/LM239/LM339 comparators

Show

CMP04FSZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Current Rating	800 µA
Output Current	16mA @5V
Supply Current	2 mA
Number of Channels	4 Channel
Number of Positions	14 Position
Power Dissipation	6.00 mW
Common Mode Rejection Ratio	100 dB
Input Offset Voltage	1 mV
Input Bias Current	40 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3.3V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	0.3 V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
