CP82C54 - Intersil
Manufacturer:
Intersil
ManyChip's Part#:
MC74751225
Category:
Timer IC
Datasheet:
Datasheet 3D Model
Description:
INTERSIL CP82C54 Timer, Oscillator & Pulse Generator IC, Programmable Interval Timer, 8MHz, 4.5V to 5.5V, DIP-24
Stock Locations:
Availability:
1,047 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 9.81

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Description
The Intersil 82C54 is a high performance CMOS Programmable Interval Timer manufactured using an advanced 2 micron CMOS process.
The 82C54 has three independently programmable and functional 16-bit counters, each capable of handling clock input frequencies of up to 8MHz (82C54) or 10MHz (82C54-10) or 12MHz (82C54-12).
Features
• 8MHz to 12MHz Clock Input Frequency
• Compatible with NMOS 8254
\- Enhanced Version of NMOS 8253
• Three Independent 16-Bit Counters
• Six Programmable Counter Modes
• Status Read Back Command
• Binary or BCD Counting
• Fully TTL Compatible
• Single 5V Power Supply
• Low Power
\- ICCSB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10µA
\- ICCOP . . . . . . . . . . . . . . . . . . . . . . . . . . 10mA at 8MHz
• Operating Temperature Ranges
\- C82C54 . . . . . . . . . . . . . . . . . . . . . . . . . .0°C to +70°C
\- I82C54 . . . . . . . . . . . . . . . . . . . . . . . . . -40°C to +85°C
\- M82C54 . . . . . . . . . . . . . . . . . . . . . . . -55°C to +125°C

Show

CP82C54 Specifications
