Description
- This 25 V, 0.49 mΩ, SON 5 × 6 mm NexFET™ power MOSFET is designed to minimize resistance for ORing and hot swap applications and is not designed for switching applications.
CSD16570Q5B Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | VSON-Clip-8 |
| Number of Channels | 1 Channel |
| Power Dissipation | 3.2 W |
| Threshold Voltage | 1.1 V |
| Drain to Source Voltage (Vds) | 25 V |
| Breakdown Voltage (Drain to Source) | 25 V |
| Rise Time | 43 ns |
| Input Capacitance (Ciss) | 14000pF @12V(Vds) |
| Fall Time | 72 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 3.2W (Ta), 195W (Tc) |
| Show | |
| Size-Width | 5 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | |
| Packaging | Tape & Reel (TR) |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
