Description

The CSD87312Q3E is a 30V common-source, dual N-channel device designed for adaptor/USB input protection. This SON 3.3 x 3.3mm device has low drain to drain on-resistance that minimizes losses and offers low component count for space constrained multi-cell battery charging applications.

Show

CSD87312Q3E Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	PowerTDFN-8
Number of Channels	2 Channel
Drain to Source Resistance (on) (Rds)	38 mΩ
Polarity	N-CH
Power Dissipation	2.5 W
Threshold Voltage	1 V
Drain to Source Voltage (Vds)	30 V
Breakdown Voltage (Drain to Source)	30 V
Continuous Drain Current (Ids)	27A
Rise Time	16 ns
Input Capacitance (Ciss)	1250pF @15V(Vds)
Input Power (Max)	2.5 W
Fall Time	2.9 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	55 ℃
Power Dissipation (Max)	2.5 W
	Show
Size-Length	3.3 mm
Size-Width	3.3 mm
Size-Height	1 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
