Description
- DESCRIPTION
- The CSD87352Q5D NexFET™ power block is an optimized design for synchronous buck applications
- offering high current, high efficiency, and high frequency capability in a small 5-mm × 6-mm outline.
- Optimized for 5V gate drive applications, this product offers a flexible solution capable of offering a high
- density power supply when paired with any 5V gate drive from an external controller/driver.
- FEATURES
- • Half-Bridge Power Block
- • 91% system Efficiency at 15A
- • High Frequency Operation (Up To 1.5MHz)
- • High Density – SON 5-mm × 6-mm Footprint
- • Optimized for 5V Gate Drive
- • Low Switching Losses
- • Ultra Low Inductance Package
- • RoHS Compliant
- • Halogen Free
- APPLICATIONS
- • Synchronous Buck Converters
- – High Frequency Applications
- – High Current, Low Duty Cycle Applications
- • Multiphase Synchronous Buck Converters
- • POL DC-DC Converters
- • IMVP, VRM, and VRD Applications
CSD87352Q5D Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | LSON-CLIP-8 |
| Power Dissipation | 8.5 W |
| Drain to Source Voltage (Vds) | 30 V |
| Rise Time | 7 ns |
| Input Capacitance (Ciss) | 1800pF @15V(Vds) |
| Input Power (Max) | 8 W |
| Fall Time | 2.7 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 8.5 W |
| Show | |
| Size-Length | 6 mm |
| Size-Width | 5 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | |
| Packaging | Tape & Reel (TR) |
| RoHS | Compliant with Exemption |
| Lead-Free Status | Contains Lead |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
| HK STC License | NLR |
