Image is for your reference only,please check specifications for details
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The CW48 series panel-mount Solid State Relay with SCR output for heavy industrial loads. It has redesigned housing with anti-rotation barriers and DBC substrate for superior thermal performance.
- LED status indicator
- Improved SEMS screw and washer
- AC or DC control and Universal AC/DC control
- EMC compliant to level 3
- Epoxy-free design
- Removable IP20 touch-safe cover
- Hazard of electric shock, explosion or arc flash. Disconnect all power before installing or working with this equipment. Verify all connections and replace all covers before turning ON power.
CWD4850 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Panel, Screw |
| Number of Pins | 4 Pin |
| Case/Package | Hockey Puck |
| Current Rating | 50 A |
| Insulation Resistance | 1.00 GΩ |
| Output Voltage | 48V ~ 660V |
| Output Current | 50000 mA |
| Contacts Type | SPST-NO |
| Load Current | 50 A |
| Input Current | 15 mA |
| Isolation Voltage | 4000 v |
| Output Voltage (Max) | 660 V |
| Load Current (Max) | 50 Arms |
| Load Current (Min) | 0.15 A |
| Operating Temperature (Max) | 80 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating | 660 VAC |
| Operating Voltage (Min) | 48 Vrms |
| Operating Voltage (Max) | 660 Vrms |
| Input Voltage | 32 V |
| Show | |
| Size-Length | 45.7 mm |
| Size-Width | 45.7 mm |
| Size-Height | 33 mm |
| Contact Material | Silver Alloy |
| Operating Temperature | -40℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| HTS Code | 8536490080 |
| ECCN Code | EAR99 |
