Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Pin Pitch | 2.74 mm |
Number of Contacts | 9 Contact |
Gender | Male |
Contact Plating | Gold |
Current Rating | 5 A |
Insulation Resistance | 1000 MΩ |
Number of Rows | 2 Row |
Flammability Rating | UL 94 V-0 |
Number of Positions | 9 Position |
Number of Mating Cycles | 200 Cycle |
Current Rating (Max) | 5A/触头 |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -55 ℃ |
Voltage Rating (Max) | 300 VAC |
Voltage Rating | 300 V |
Operating Voltage (Max) | 300 VAC |
Maximum Contact Resistance (Max) | 10 mΩ |
Show | |
Size-Length | 30.81 mm |
Size-Width | 18.5 mm |
Size-Height | 12.58 mm |
Housing Color | Black |
Color | Black |
Contact Material | Copper Alloy |
Operating Temperature | -55℃ ~ 125℃ |
Housing Material | Plastic |
Product Lifecycle Status | Active |
Packaging | Tray |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
