Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The D1D07 is a Solid-state Relay with panel mount, 1-DC series. DC output, MOSFET output. Redesigned housing with anti-rotation barriers. Easily paralleled for higher current applications.
- Improved SEMS screw and washer
- EMC compliant to Level 3
- Epoxy-free design
- UL94V-0 Flammability rating
D1D07 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 4 Pin |
| Case/Package | Hockey Puck |
| Supply Voltage (DC) | 3.50V (min) |
| Operating Voltage | 100V (max) |
| Current Rating | 7 A |
| Output Voltage | ≤100 V |
| Output Current | 7000 mA |
| Contacts Type | SPST-NO |
| Load Current | 7 A |
| Input Current | 15 mA |
| Isolation Voltage | 3750 v |
| Input Voltage (Max) | 32 V |
| Input Voltage (Min) | 3.5 V |
| Output Voltage (Max) | 100 V |
| Output Current (Max) | 7 A |
| Input Current (Min) | 15 mA |
| Load Current (Max) | 7 A |
| Load Current (Min) | 1 mA |
| Operating Temperature (Max) | 80 ℃ |
| Operating Temperature (Min) | -20 ℃ |
| Voltage Rating | 100 VDC |
| Operating Voltage (Min) | 0 VDC |
| Operating Voltage (Max) | 100 VDC |
| Input Voltage | 32 V |
| Show | |
| Size-Length | 45.7 mm |
| Size-Width | 45.7 mm |
| Size-Height | 23 mm |
| Operating Temperature | -20℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| HTS Code | 8536490080 |
| ECCN Code | EAR99 |
