Image is for your reference only,please check specifications for details

DAC08EPZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC459604
Category:
Digital to Analog, DAC IC
Package:
DIP-16
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES DAC08EPZ Digital to Analog Converter, 8Bit, 11.8MSPS, Parallel, ± 4.5V to ± 18V, DIP, 16Pins
Stock Locations:
Availability:
236 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.2

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DAC08EPZ is an 8-bit monolithic Digital-to-analog Converter provides very high speed performance coupled with outstanding applications flexibility. Advanced circuit design achieves 85ns settling times with very low glitch energy and at low power consumption. Monotonic multiplying performance is attained over a wide 20-to-1 reference current range. Matching to within 1LSB between reference and full-scale currents eliminates the need for full-scale trimming in most applications. Direct interface to all popular logic families with full noise immunity is provided by the high swing, adjustable threshold logic input. High voltage compliance complementary current outputs are provided, increasing versatility and enabling differential operation to effectively double the peak-to-peak output swing. In many applications, the outputs can be directly converted to voltage without the need for an external op amp.
Fast settling output current
Direct interface to TTL, CMOS, ECL, HTL, PMOS
Nonlinearity to 0.1% maximum over temperature range
-10 to 18V High output impedance and compliance
Complementary current outputs
Wide range multiplying capability - 1MHz bandwidth
Low FS current drift - ±10ppm/°C

Show

DAC08EPZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Number of Outputs	1 Output
Supply Current	-6.50 mA
Number of Channels	1 Channel
Number of Positions	16 Position
Number of Bits	8 Bit
Power Dissipation	0.174 W
Sample Rate	11.8 Msps
Resolution (Bits)	8.0 Bit
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	174 mW
Number of DACs	1 DAC
	Show
Size-Length	20.07 mm
Size-Width	6.35 mm
Size-Height	3.3 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
