Image is for your reference only,please check specifications for details

DF005M - Fairchild
Manufacturer:
Fairchild
ManyChip's Part#:
MC38884183
Category:
Bridge Rectifier
Package:
DIP-4
Datasheet:
Datasheet 3D Model
Description:
FAIRCHILD SEMICONDUCTOR DF005M Bridge Rectifier Diode, Single, 50V, 1.5A, DIP, 1.1V, 4Pins
Stock Locations:
Availability:
150 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.23

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DF005M is a 4-pin single-phase Bridge Rectifier Diode with glass passivated junction.
Low leakage
50A Surge overload rating
35V Maximum RMS bridge input voltage
-55 to 150°C Operating temperature range

Show

DF005M Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	DIP-4
Voltage Rating (DC)	50.0 V
Current Rating	1.50 A
Capacitance	25.0 pF
Output Current	≤1.50 A
Number of Positions	4 Position
Forward Voltage	1.1V @1A
Power Dissipation	3.1 W
Forward Current	1.5 A
Max Forward Surge Current (Ifsm)	50 A
Maximum Forward Voltage (Max)	1.1 V
Forward Current (Max)	1.5 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	3100 mW
	Show
Size-Length	8.51 mm
Size-Width	6.48 mm
Size-Height	3.3 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
