DG407DYZ - Intersil
Manufacturer:
Intersil
ManyChip's Part#:
MC55247363
Category:
Multiplexer IC
Package:
SOIC-28
Datasheet:
Datasheet 3D Model
Description:
Single 16Channel/Differential 8Channel, CMOS Analog Multiplexers; PDIP28, SOIC28; Temp Range: -40° to 85℃
Stock Locations:
Availability:
143 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 6.3

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The DG407DYZ is a monolithic CMOS Analog Multiplexer, drop-in replacements for the popular DG507A series devices. They each include an array of sixteen analog switches, a TTL and CMOS compatible digital decode circuit for channel selection, a voltage reference for logic thresholds and an ENABLE input for device selection when several multiplexers are present. These multiplexers feature lower signal on-resistance (<300ns). Charge injection has been reduced, simplifying sample and hold applications. An epitaxial layer prevents the latch-up associated with older CMOS technologies. The 44V maximum voltage range permits controlling 30Vp-p signals when operating with ±15V power supplies. The sixteen switches are bilateral, equally matched for AC or bidirectional signals. The on-resistance variation with analog signals is quite low over a ±5V analog input range.
<12mW Low power consumption (PD)
300ns (maximum) Fast transition time
Low charge injection
TTL, CMOS compatible

Show

DG407DYZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	SOIC-28
Supply Voltage (DC)	44.0V (max)
Number of Outputs	2 Output
Supply Current	80 µA
Number of Circuits	2 Circuit
Number of Channels	8 Channel
Number of Positions	28 Position
Drain to Source Resistance (on) (Rds)	100 Ω
Power Dissipation	1.2 W
Number of Inputs	16 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
