Description

The FS25R12W1T4 is an EconoPACK™ 1B IGBT Module with Trench/field-stop IGBT4, emitter controlled 4 diode and NTC. It is suitable for air conditioning and servo drives.
Low switching losses
V(CEsat) with positive temperature coefficient
Al2O₃ substrate with low thermal resistance
Compact design
Solder contact technology
Rugged mounting due to integrated mounting clamps
Compact module concept
Configuration flexibility

Show

FS25R12W1T4 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Screw
Number of Pins	18 Pin
Case/Package	AG-EASY1B-1
Number of Positions	18 Position
Polarity	N-Channel
Power Dissipation	205 W
Breakdown Voltage (Collector to Emitter)	1200 V
Input Capacitance (Cies)	1.45nF @25V
Input Power (Max)	205 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	205 W
	Show
Size-Length	33.8 mm
Size-Width	33.8 mm
Size-Height	12 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	PB free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
HK STC License	NLR
