Image is for your reference only,please check specifications for details
- FS820R08A6P2B - Infineon
-
Manufacturer:Infineon
-
ManyChip's Part#:MC194099538
-
Package:AG-HYBRIDD-1
-
Datasheet:Datasheet 3D Model
-
Description:Модуль привода HybridPACK™ с EDT2 IGBT и диодом — это автомобильный квалифицированный силовой модуль, предназначенный для применения в гибридных и электрических транспортных средствах. Найдите подходящий автомобильный EiceDRIVER™.
-
Stock Locations:
-
Availability:288 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 990.08
Updated at 19/08/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Краткий обзор характеристик:
- Блокирующее напряжение 750 В
- Низкое напряжение насыщения коллектор-эмиттер (VCEsat)
- Низкие потери при переключении
- Низкий заряд затвора (QG) и низкая обратная емкость (Cres)
- Низкоиндуктивная конструкция
- Рабочая температура перехода Tvj op = 150°C
- Кратковременная повышенная рабочая температура перехода Tvj op = 175°C
- Преимущества:
- Компактная конструкция
- Непосредственно охлаждаемое основание
- Направляющие элементы для сборки печатной платы и охладителя
- Встроенный датчик температуры NTC
- Технология контактов PressFIT
- Соответствует требованиям RoHS
FS820R08A6P2B Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 33 Pin |
| Case/Package | AG-HYBRIDD-1 |
| Operating Temperature (Max) | 175 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 714000 mW |
| Show | |
| Product Lifecycle Status | Active |
| RoHS | Compliant with Exemption |
| Lead-Free Status | Lead Free |
