Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 32 Pin |
Case/Package | SPM32-AA |
Frequency | 15.0 kHz |
Supply Voltage (DC) | 450V (max) |
Number of Outputs | 1 Output |
Input Voltage (DC) | 15.0 V |
Output Voltage | ≤4.50 V |
Output Current | 5 mA |
Power Dissipation | 62 W |
Isolation Voltage | 2500 Vrms |
Breakdown Voltage (Collector to Emitter) | 600 V |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -20 ℃ |
Power Dissipation (Max) | 62000 mW |
Supply Voltage | 13.5V ~ 16.5V |
Show | |
Size-Length | 60 mm |
Size-Width | 31 mm |
Size-Height | 7.2 mm |
Operating Temperature | -20℃ ~ 125℃ |
Product Lifecycle Status | Not Recommended for New Designs |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
