Description
- The H12WD series panel-mount Solid State Relay with low OFF-state leakage current (snubberless). It has redesigned housing with anti-rotation barriers.
- SCR output for heavy industrial loads
- Zero voltage or instantaneous turn-on outputs
- Improved SEMS screw and washer
- DC control
- Direct bond copper substrate
- EMC compliant to level 3
- Direct power lead frame
- Epoxy-free design
- Hazard of electric shock, explosion or arc flash. Disconnect all power before installing or working with this equipment. Verify all connections and replace all covers before turning ON power.
H12WD4850PG Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Screw |
| Number of Pins | 4 Pin |
| Case/Package | Hockey Puck |
| Current Rating | 50 A |
| Load Current | 50 A |
| Resistance | 1500 Ω |
| Isolation Voltage | 4 kV |
| Input Voltage (Max) | 32 V |
| Input Voltage (Min) | 4 V |
| Input Current (Min) | 12 mA |
| Load Current (Max) | 50 A |
| Load Current (Min) | 150 mArms |
| Operating Temperature (Max) | 80 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Operating Voltage (Min) | 48 Vrms |
| Operating Voltage (Max) | 660 Vrms |
| Input Voltage | 4VDC ~ 32VDC |
| Show | |
| Size-Length | 58.4 mm |
| Size-Height | 22.9 mm |
| Operating Temperature | -40℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| HTS Code | 8536490080 |
| ECCN Code | EAR99 |
