HCPL0611 - Fairchild
Manufacturer:
Fairchild
ManyChip's Part#:
MC53916630
Category:
Optocoupler, Optoisolator
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
FAIRCHILD SEMICONDUCTOR HCPL0611 Optocoupler, Digital Output, 1Channel, 3.75kV, 10Mbps, SOIC, 8Pins
Stock Locations:
Availability:
1,236 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.59

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

HCPL0611 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Rise/Fall Time	50ns, 12ns
Input Voltage (DC)	1.75V (max)
Output Voltage	7 V
Output Current	0.05 A
Number of Channels	1 Channel
Number of Positions	8 Position
Forward Voltage	1.75 V
Input Current	15 mA
Power Dissipation	0.085 W
Data Rate	10.0 Mbps
Rise Time	50 ns
Isolation Voltage	3750 Vrms
Forward Current	50 mA
Input Voltage (Max)	1.8 V
Input Current (Min)	50 mA
Reverse Breakdown Voltage	5 V
Maximum Forward Voltage (Max)	1.8 V
Forward Current (Max)	50 mA
Fall Time	12 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	85 mW
Supply Voltage	4.5V ~ 5.5V
	Show
Size-Length	5.13 mm
Size-Width	4.16 mm
Size-Height	3.43 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
