Description
- The HEF4555BP is an 1-of-4 Decoder/Demultiplexer has two address inputs (nA0 and nA1, an active low enable input (nE\\) and four mutually exclusive outputs which are active high (nY0 to nY3). When used as a decoder, nE\ when high, forces nY0 to nY3 low. When used as a demultiplexer, the appropriate output is selected by the information on nA0 and nA1 with nE\ as data input. All unselected outputs are low. It operates over a recommended VDD power supply range of 3 to 15V referenced to VSS (usually ground). Unused inputs must be connected to VDD, VSS or another input.
- Fully static operation
- Standardized symmetrical output characteristics
- Complies with JEDEC standard JESD 13-B
HEF4555BP Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 16 Pin |
| Case/Package | DIP |
| Number of Outputs | 4 Output |
| Number of Channels | 2 Channel |
| Number of Positions | 16 Position |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage (Max) | 15.5 V |
| Supply Voltage (Min) | 4.5 V |
| Show | |
| RoHS | RoHS Compliant |
