Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | DIP |
Voltage Rating (DC) | 28 V |
Current Rating | 4 A |
Input Voltage (DC) | 26.5 V |
Contacts Type | DPDT |
Power Consumption | 1.003 W |
Contact Current Rating | 4 A |
Coil Voltage | 26.5 VDC |
Coil Current | 37.86 mA |
Coil Power (DC) | 1.00 W |
Coil Resistance | 700 Ω |
Current Rating (Max) | 2 A |
Coil Voltage (DC) | 26.5 V |
Coil Power | 1 W |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -65 ℃ |
Voltage Rating | 26.5 VDC |
Voltage Rating (DC Max) | 28 V |
Show | |
Size-Length | 20.57 mm |
Size-Width | 10.4 mm |
Size-Height | 10.41 mm |
Contact Material | Silver, Gold |
Operating Temperature | -65℃ ~ 125℃ |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | Non-Compliant |
Lead-Free Status | Contains Lead |
ELV Compliant | Non-Compliant |
HTS Code | 8536410050 |
ECCN Code | EAR99 |
