HIP4086APZ - Intersil
Manufacturer:
Intersil
ManyChip's Part#:
MC78291541
Category:
FET Driver
Package:
DIP-24
Datasheet:
Datasheet 3D Model
Description:
Intersil HIP4086APZ, Hex MOSFET Power Driver 1.5A Three Phase, 7 → 15V, 24Pin PDIP
Stock Locations:
Availability:
33 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.22

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

HIP4086APZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	24 Pin
Case/Package	DIP-24
Supply Voltage (DC)	7.00V (min)
Rise/Fall Time	20ns, 10ns
Number of Outputs	6 Output
Output Voltage	101.3 V
Output Current	500 mA
Output Voltage (Max)	80 V
Output Current (Max)	1.5 A
Fall Time (Max)	20 ns
Fall Time (Max)	40 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	7V ~ 15V
Supply Voltage (Max)	15 V
Supply Voltage (Min)	7 V
	Show
Size-Length	32.51 mm
Size-Width	7.11 mm
Size-Height	4.95 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
