Description
- Product Details
- The HMC1127 is a GaAs pHEMT MMIC Distributed Power Amplifier which operates between 2 and 50 GHz. The amplifier provides 14.5 dB of gain, 23 dBm output IP3 and 12.5 dBm of output power at 1 dB gain compression while requiring 80 mA from a +5V supply. The HMC1127 amplifier I/Os are internally matched to 50 Ohms facilitating integration into Multi-Chip-Modules (MCMs). All data is taken with the chip connected via two 0.025 mm (1 mil) wire bonds of minimal length 0.31 mm (12 mils).
- Applications
- Test Instrumentation
- Microwave Radio & VSAT
- Military & Space
- Telecom Infrastructure
- Fiber Optics
- ### Features and Benefits
- P1dB Output Power: 12.5 dBm
- Psat Output Power: 17.5 dBm
- Gain: 14.5 dB
- Output IP3: 23 dBm
- Supply Voltage: +5 V@80 mA
- 50 Ohm Matched Input/Output
- Die Size: 2.7 x 1.45 x 0.1 mm
HMC1127 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 5 Pin |
| Case/Package | C-5 |
| Power Dissipation | 2530 mW |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 2530 mW |
| Show | |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Contains Lead |
