HMC260LC3B - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC22726064
Category:
Active Chip
Package:
VFCQFN-12
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC260LC3B RF Double Balanced Mixer IC, RF/LO Range 14GHz to 26GHz, HQFN-12
Stock Locations:
Availability:
18 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 55.62

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The HMC260LC3B is a general purpose GaAs MMIC fundamental Double-balanced Mixer used as an up-converter or down-converter between 14 and 26GHz. This mixer requires no external components or matching circuitry. The HMC260LC3B provides excellent LO to RF and LO to IF suppression due to optimized balun structures. The mixer operates with LO drive levels above +9dBm. The HMC260LC3B eliminates the need for wire bonding, allowing use of surface mount manufacturing techniques.
Passive - no DC bias required
20dBm Input IP3
40dB LO/RF isolation
DC to 8GHz Wide IF bandwidth

Show

HMC260LC3B Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	12 Pin
Case/Package	VFCQFN-12
Frequency	14GHz ~ 26GHz
Number of Positions	12 Position
Power Dissipation	0.26 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	260 mW
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.92 mm
Product Lifecycle Status	End of Life
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
