Description

Pout: +14 dBm Phase Noise: -103 dBc/Hz @100 KHz No External Resonator Needed Single Supply: +3V @ 77 mA QFN Leadless SMT Package, 16 mm2

Show

HMC506LP4E Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	QFN-24
Frequency	7.8GHz ~ 8.7GHz
Supply Current	77 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3 V
	Show
Size-Length	4.1 mm
Size-Width	4.1 mm
Size-Height	1 mm
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
