HMC7992LP3DETR - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC392404
Category:
RF Module
Package:
LFCSP-16
Datasheet:
Datasheet 3D Model
Description:
RF Switch IC, SP4T, 100MHz to 6GHz, TTL, CMOS, 3.3V to 5V, LFCSP-16
Stock Locations:
Availability:
213 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.58

Updated at 31/10/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

GENERAL DESCRIPTION
The HMC7992is a general-purpose, nonreflective, 0.1 GHz to 6.0 GHz, silicon, single-pole, four-throw (SP4T) switch in a leadless, surface-mount package. The switch is ideal for cellular infrastructure applications, offers high isolation of 45 dB typical at 2 GHz, and a low insertion loss of 0.6 dB at 2 GHz. It offers excellent power handling capability up to 6.0 GHz, with input power of 1 dB compression point (P1dB) of 35 dBm at 5 V operation.
FEATURES
Nonreflective, 50 Ω design
High isolation: 45 dB typical at 2 GHz
Low insertion loss: 0.6 dB at 2 GHz
High power handling
33 dBm through path
27 dBm terminated path
High linearity
1 dB compression (P1dB): 35 dBm typical
Input third-order intercept (IIP3): 58 dBm typical
ESD rating: 2 kV human body model (HBM), Class 2
Single positive supply: 3.3 V to 5.0 V
Standard TTL-, CMOS-, and 1.8 V-compatible control
16-lead, 3 mm × 3 mm LFCSP package (9 mm2)
Pin compatible with the HMC241ALP3E
APPLICATIONS
Cellular/4G infrastructure
Wireless infrastructure
Automotive telematics
Mobile radios
Test equipment
