Description
- The IHLP6767GZER101M11 is a surface mount IHLP® shielded High-current Inductor handles high transient current spikes without saturation. This low profile inductor features excellent DC/DC energy storage up to 1 to 2MHz and an ultra-low buzz noise, due to its composite construction.
- Shielded construction
- Lowest DCR/µH
- Halogen-free
IHLP6767GZER101M11 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | 6767 |
| Current Rating | 5 A |
| Capacitance Tolerance | ±20 % |
| Inductance | 100 µH |
| Self Resonant Frequency | 2.1 MHz |
| Part Family | IHLP |
| Resistance | 105 mΩ |
| Inductance Tolerance | ±20 % |
| Test Frequency | 0.1 MHz |
| DC Resistance (DCR) | 0.11 Ω |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Resistance (DC Max) | 110 mΩ |
| Show | |
| Size-Length | 17.15 mm |
| Size-Width | 17.1 mm |
| Size-Height | 7 mm |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
