Description

The IKW40N120T2 is a Low Loss IGBT in 2nd generation TrenchStop® technology with soft, fast recovery anti-parallel emitter controlled diode. The TrenchStop® IGBT technology leads to significant improvement of static as well as dynamic performance of the device, due to combination of TrenchStop®-cell and field-stop concept. The combination of IGBT with soft recovery emitter controlled diode further minimizes the turn-ON losses. The highest efficiency is reached due to the best compromise between switching and conduction losses.
Lowest Vce (sat) drop for lower conduction losses
Low switching losses
Easy parallel switching capability due to positive temperature coefficient in Vce (sat)
Very soft, fast recovery anti-parallel emitter controlled HE diode
High ruggedness, temperature stable behaviour
Low EMI emissions
Low gate charge
Very tight parameter distribution
Highest efficiency - Low conduction and switching losses
High device reliability
10µs Short-circuit withstand time

Show

IKW40N120T2FKSA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-247-3
Number of Positions	3 Position
Power Dissipation	480 W
Breakdown Voltage (Collector to Emitter)	1200 V
Reverse recovery time	258 ns
Input Power (Max)	480 W
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	480000 mW
	Show
Size-Length	16.13 mm
Size-Width	5.21 mm
Size-Height	21.1 mm
Operating Temperature	-40℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99
