Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 6 Pin |
Case/Package | SC-74-6 |
Voltage Rating (DC) | 50.0 V |
Current Rating | 30.0 mA |
Power Rating | 0.3 W |
Polarity | N-Channel, P-Channel |
Power Dissipation | 300 mW |
Breakdown Voltage (Collector to Emitter) | 50 V |
Continuous Collector Current | 100mA |
hFE Min | 56 @5mA, 5V |
Input Power (Max) | 300 mW |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Gain Bandwidth | 250 MHz |
Power Dissipation (Max) | 300 mW |
Show | |
Size-Length | 3 mm |
Size-Width | 1.8 mm |
Size-Height | 1.2 mm |
Operating Temperature | -55℃ ~ 150℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
