Description

The IP4234CZ6 is a single USB 2.0 ESD Protection Device designed to protect input/output (I/O) USB 2.0 ports that are sensitive to capacitive loads, from being damaged by electrostatic discharge (ESD). The π-filter structure is implemented with a small series resistor to provide the necessary protection to signal and supply components from ESD voltages greater than ±8kV contact discharge according IEC 61000-4-2, level 4. The ESD protection is independent of the supply voltage due to the rail-to-rail diode architecture being connected to a Zener diode. It is fabricated using monolithic silicon technology and integrates two ultra-low capacitance π-filter ESD protection diodes plus a Zener diode.
Simple, direct signal routing provides for high speed signal integrity
Significant reduction in peak clamping and peak residual current
Four low input capacitance (2.0pF typical) rail-to-rail ESD protection diodes
Low voltage clamping due to an integrated Zener diode
IEC 61000-4-5 15A Lightning (8/20µs) compliant

Show

IP4234CZ6 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-457
Operating Voltage	3 V
Number of Positions	6 Position
Power Dissipation	100 W
Test Current	1 mA
Peak Pulse Power	100 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	3.1 mm
Size-Width	1.7 mm
Size-Height	1 mm
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
