Description
- Summary of Features:
- Reduced gate charge (Q g)
- Higher V th
- Good body diode ruggedness
- Optimized integrated R g
- Improved dv/dt from 50V/ns
- CoolMOS™ quality with over 12 years manufacturing experience in superjunction technology
- Benefits:
- Improved effciency especially in light load condition
- Better efficiency in soft switching applications due to earlier turn-off
- Suitable for hard- & soft-switching topologies
- Optimized balance of efficiency and ease of use and good controllability of switching behavior
- High robustness and better efficiency
- Outstanding quality & reliability
IPA60R230P6 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 3 Pin |
| Case/Package | TO-220-3 |
| Number of Channels | 1 Channel |
| Drain to Source Resistance (on) (Rds) | 230 Ω |
| Polarity | N-CH |
| Power Dissipation | 33 W |
| Drain to Source Voltage (Vds) | 600 V |
| Breakdown Voltage (Drain to Source) | 600 V |
| Continuous Drain Current (Ids) | 16.8A |
| Rise Time | 7 ns |
| Input Capacitance (Ciss) | 1450pF @100V(Vds) |
| Fall Time | 6 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 33000 mW |
| Show | |
| Size-Length | 10.65 mm |
| Size-Width | 4.85 mm |
| Size-Height | 16.15 mm |
| Product Lifecycle Status | Active |
| Packaging | Rail, Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
