IRF7420 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC
Voltage Rating (DC)	-12.0 V
Current Rating	-11.5 A
Polarity	P-Channel
Power Dissipation	2.50 W
Part Family	IRF7420
Drain to Source Voltage (Vds)	12.0 V
Breakdown Voltage (Drain to Source)	-12.0 V
Continuous Drain Current (Ids)	11.5 A
Rise Time	8.80 ns
	Show
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
