- IRS2453DSPBF - Infineon
-
Manufacturer:Infineon
-
ManyChip's Part#:MC6865140
-
Category:FET Driver
-
Package:SOIC-14
-
Datasheet:Datasheet 3D Model
-
Description:MOSFET DRVR 600V 0.26A 4Out Hi/Lo Side Full Brdg Inv/Non-Inv 14Pin SOIC N Tube
-
Stock Locations:
-
Availability:257 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.85
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- IRS2453 Series 600 V 180 mA 15.6 V Supply Quad Full Bridge Driver - SOIC-14N
IRS2453DSPBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | SOIC-14 |
| Supply Voltage (DC) | 10.0V (min) |
| Power Rating | 1 W |
| Rise/Fall Time | 120ns, 50ns |
| Number of Outputs | 4 Output |
| Output Voltage | 600 V |
| Output Current | 180.260 mA |
| Number of Channels | 4 Channel |
| Quiescent Current | 1.3 mA |
| Rise Time | 120 ns |
| Output Voltage (Max) | 20.0 V |
| Fall Time | 50 ns |
| Fall Time (Max) | 100 ns |
| Fall Time (Max) | 200 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Supply Voltage | 10V ~ 15.6V |
| Supply Voltage (Max) | 20 V |
| Supply Voltage (Min) | 10 V |
| Show | |
| Size-Length | 8.74 mm |
| Size-Width | 3.99 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -25℃ ~ 125℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
