- ISL6115CBZA - Intersil
-
Manufacturer:Intersil
-
ManyChip's Part#:MC86531469
-
Category:Power Distribution
-
Package:SOIC-8
-
Datasheet:Datasheet 3D Model
-
Description:INTERSIL ISL6115CBZA Hot Swap Power Controller, 10.2V to 13.8V supply, 6V/75mA output, SOIC-8
-
Stock Locations:
-
Availability:264 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.19
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Power Distribution Controllers
- This family of fully featured hot swap power controllers targets applications in the +2.5V to +12V range. The
- ISL6115 is for +12V control, the ISL6116 for +5V, the ISL6117 for +3.3V and the ISL6120 for +2.5V control
- applications. Each has a hard wired undervoltage (UV) monitoring and reporting threshold level approximately
- 80% of the aforementioned voltage.
- Features
- • HOT SWAP Single Power Distribution Control (ISL6115 for +12V, ISL6116 for +5V, ISL6117 for +3.3V and ISL6120 for +2.5V)
- • Overcurrent Fault Isolation
- • Programmable Current Regulation Level
- • Programmable Current Regulation Time to Latch-Off
- • Rail-to-Rail Common Mode Input Voltage Range (ISL6115)
- • Internal Charge Pump Allows the Use of N-Channel MOSFET for +12V Control (ISL6115)
- • Undervoltage and Overcurrent Latch Indicators
- • Adjustable Turn-On Ramp
- • Protection During Turn-On
- • Two Levels of Overcurrent Detection Provide Fast Response to Varying Fault Conditions
- • 1µs Response Time to Dead Short
- • Pb-Free Available (RoHS Compliant)
- Applications
- • Power Distribution Control
- • Hot Plug Components and Circuit
ISL6115CBZA Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Supply Voltage (DC) | 10.2V (min) |
| Output Voltage | 6.00 V |
| Supply Current | 3 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Supply Voltage | 10.2V ~ 13.8V |
| Supply Voltage (Max) | 13.8 V |
| Supply Voltage (Min) | 10.2 V |
| Show | |
| Operating Temperature | 0℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
