Image is for your reference only,please check specifications for details

LM339DT - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC296940
Category:
Comparator, Analog Comparator IC
Package:
SOIC-14
Datasheet:
Datasheet 3D Model
Description:
STMICROELECTRONICS LM339DT Analog Comparator, Quad, Precision Voltage, 4, 1.3µs, 2V to 36V, SOIC, 14Pins
Stock Locations:
Availability:
3,438 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.13

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The LM339DT is a low-power quad Precision-Voltage Comparator with an offset voltage specification as low as 2mV maximum. The comparator has been designed specifically to operate from a single power supply over a wide range of voltages. Operation from split power supplies is also possible. This comparator also has unique characteristic in that the input common mode voltage range includes ground even though operated from a single power supply voltage.
Very low supply current (1.1mA) - independent of supply voltage
Input common-mode voltage range includes ground
250mV Low output saturation voltage
Differential input voltage range equal to the power supply voltage
TTL, DTL, ECL, MOS, CMOS compatible outputs

Show

LM339DT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	2.00V (min)
Operating Voltage	2V ~ 36V
Output Current	16mA @5V
Supply Current	2 mA
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	14 Position
Power Dissipation	830 mW
Quiescent Current	2.5 mA
Input Offset Voltage	5 mV
Input Bias Current	250 nA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	2V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	2 V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.65 mm
Weight	0.004535924 kg
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
