- LM46002PWPT - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC13264090
-
Category:Voltage Regulator
-
Package:HTSSOP-16
-
Datasheet:Datasheet 3D Model
-
Description:Conv DC-DC 3.5V to 60V Step Down Single-Out 1V to 28V 2A 16Pin HTSSOP EP T/R
-
Stock Locations:
-
Availability:216 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.82
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The LM46002PWPT is a SIMPLE SWITCHER® Synchronous Step-down Voltage Converter capable of driving up to 2A of load current from an input voltage ranging from 3.5V to 60V. The LM46002 provides exceptional efficiency, output accuracy and drop-out voltage in a very small solution size. Peak current mode control is employed to achieve simple control loop compensation and cycle-by-cycle current limiting. Optional features such as programmable switching frequency, synchronization, power-good flag, precision enable, internal soft-start, extendable soft-start and tracking provide a flexible and easy to use platform for a wide range of applications. Discontinuous conduction and automatic frequency reduction at light loads improve light load efficiency. The family requires few external components. Pin arrangement allows simple, optimum PCB layout. Protection features include thermal shutdown, VCC under-voltage lockout, cycle-by-cycle current limit and output short circuit protection.
- 27µA Quiescent current in regulation
- High efficiency at light load
- Meets EN55022/CISPR 22 EMI standards
- Integrated synchronous rectification
- Frequency synchronization to external clock
- Internal compensation
- Stable with almost any combination of ceramic, polymer, tantalum and aluminium capacitors
- Power-good flag
- Soft-start into pre-biased load
- Extendable soft-start time by external capacitor
- Output voltage tracking capability
- Precision enable to program system UVLO
- Output short-circuit protection with hiccup mode
- Over-temperature thermal shutdown protection
- Green product and no Sb/Br
- This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
LM46002PWPT Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | HTSSOP-16 |
| Number of Outputs | 1 Output |
| Output Voltage | 1V ~ 28V |
| Output Current | 2 A |
| Number of Positions | 16 Position |
| Quiescent Current | 27.0 µA |
| Number of Regulated Outputs | 1 Output |
| Switching Frequency | 2.2 MHz |
| Topology | Buck |
| Switching Current | 4.5 A |
| Input Voltage (Max) | 60 V |
| Input Voltage (Min) | 3.5 V |
| Output Voltage (Max) | 28 V |
| Output Voltage (Min) | 1 V |
| Output Current (Max) | 2 A |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 60 V |
| Show | |
| Size-Length | 5.1 mm |
| Size-Width | 4.5 mm |
| Size-Height | 1.05 mm |
| Operating Temperature | -40℃ ~ 125℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
