- LM5141QRGERQ1 - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC117732932
-
Category:Voltage Regulator
-
Package:VQFN-24
-
Datasheet:Datasheet 3D Model
-
Description:DC-DC Cntrlr Single-OUT Step Down 460kHz Automotive 24Pin VQFN EP T/R
-
Stock Locations:
-
Availability:295 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 10.77
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Buck Regulator Positive Output Step-Down DC-DC Controller IC 24-VQFN (4x4)
LM5141QRGERQ1 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 24 Pin |
| Case/Package | VQFN-24 |
| Number of Outputs | 1 Output |
| Output Voltage | 1.5V ~ 15V |
| Output Current | 20 A |
| Quiescent Current | 35.0 µA |
| Number of Regulated Outputs | 1 Output |
| Rise Time | 4 ns |
| Switching Frequency | 440kHz, 2.2MHz |
| Input Voltage (Max) | 65 V |
| Input Voltage (Min) | 3.8 V |
| Output Current (Max) | 20 A |
| Maximum Duty Cycle | 78 % |
| Fall Time | 3 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | 40 ℃ |
| Input Voltage | 3.8V ~ 65V |
| Show | |
| Operating Temperature | -40℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status |
