LMC7111BIM5X Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	SOT-23-5
Supply Voltage (DC)	2.70 V
Operating Voltage	2.5V ~ 11V
Output Current	7.00 mA
Supply Current	25 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Common Mode Rejection Ratio	60 dB
Input Offset Drift	2.00 µV/K
Bandwidth	40 kHz
Slew Rate	27.0 mV/μs
Gain Bandwidth Product	0.05 MHz
Input Offset Voltage	900 µV
Input Bias Current	0.1 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	50 kHz
Supply Voltage	2.7V ~ 11V
Supply Voltage (Max)	11 V
	Show
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
