Image is for your reference only,please check specifications for details
- MAX3232EUE - MaximIntegrated
-
Manufacturer:MaximIntegrated
-
ManyChip's Part#:MC34316800
-
Category:Interface ICs
-
Package:TSSOP-16
-
Datasheet:Datasheet 3D Model
-
Description:Интерфейс RS-232 IC, напряжение 3 В до 5,5 В, низкое энергопотребление, скорость передачи данных до 1 Мбит/с; поддерживает реальный формат RS-232-передатчиков и приемников с использованием четырех внешних конденсаторов емкостью 0,1 Ф.
-
Stock Locations:
-
Availability:241 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.14
Updated at 31/10/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Передатчик-приемник 2/2 стандарта RS232, корпус типа 16-TSSOP.
MAX3232EUE Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 16 Pin |
| Case/Package | TSSOP-16 |
| Supply Voltage (DC) | 3.00V (min) |
| Supply Current | 300 µA |
| Data Rate | 120 kbps |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | 40 ℃ |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 5 mm |
| Size-Width | 4.4 mm |
| Size-Height | 0.9 mm |
| Product Lifecycle Status | Unknown |
| Packaging | Pack |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
