- MAX4066CPD - Maxim Integrated
-
Manufacturer:Maxim Integrated
-
ManyChip's Part#:MC151289927
-
Category:Analog Switch Ic, Analog Switch Multiplexer
-
Package:PDIP-14
-
Datasheet:Datasheet 3D Model
-
Description:SPST, 4 Func, 1Channel, CMOS, PDIP14, 0.3INCH, PLASTIC, DIP-14
-
Stock Locations:
-
Availability:621 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 3.24
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- General Description
- The MAX4066/MAX4066A quad, SPST, CMOS analog switches are designed to provide superior performance over the industry-standard devices. These new switch es feature guaranteed operation from +2.0V to +16V and are fully specified at 3V, 5V, and 12V. Both parts offer 45Ωon-resistance and 2Ωchannel-to-channel matching at 12V, plus 4Ωflatness over the specified signal range.
- Features
- ♦Pin Compatible with 74HC4066
- ♦Guaranteed On-Resistance:
- 170Ωmax (3V supply)
- 45Ωmax (12V supply)
- ♦Guaranteed Match Between Channels:
- 4Ωmax (MAX4066)
- 2Ωmax (MAX4066A)
- ♦Guaranteed Low Leakage Currents:
- 1nA at +25°C (MAX4066)
- 100pA at +25°C (MAX4066A)
- ♦Single-Supply Operation from +2.0V to +16V
- ♦V+ to GND Signal Handling
- ♦TTL/CMOS-Logic Compatible
- ♦Low Power Consumption: 0.5µW
- ♦Low Crosstalk: -86dB
- ♦Low Off Isolation: -58dB
- ♦Low Distortion: 0.03%
- ♦Wide Bandwidth: > 100MHz
- Applications
- Battery-Operated Equipment
- Audio and Video Signal Routing
- Low-Voltage Data-Acquisition Systems
- Sample-and-Hold Circuits
- Communication Circuits
MAX4066CPD Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 14 Pin |
| Case/Package | PDIP-14 |
| Supply Voltage (DC) | 15.0 V |
| Contacts Type | SPST |
| Number of Circuits | 4 Circuit |
| Number of Bits | 4 Bit |
| Power Dissipation | 800 mW |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| 3dB Bandwidth | 100 MHz |
| Power Dissipation (Max) | 800 mW |
| Supply Voltage (Max) | 16 V |
| Supply Voltage (Min) | 2 V |
| Show | |
| Size-Length | 19.43 mm |
| Size-Width | 7.87 mm |
| Size-Height | 4.45 mm |
| Operating Temperature | 0℃ ~ 70℃ (TA) |
| Product Lifecycle Status | Unknown |
| Packaging | Tube, Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
Order guide
-
TT in advance (bank transfer), Western Union, Credit card,
PayPal. Customer is responsible for shipping fee, bank
charges, duties and taxes.
-
- You can choose whether shipping charges will be charged through your shipping account or by us.
- Please confirm with the logistics company in advance for remote areas.
(Additional charges ($35-$50) may apply for delivery in these areas)
- Delivery date: usually 2 to 7 working days.
- A tracking number will be sent after your order ships.
- - Carefully inspected and packed by ManyChip warehouse - Vacuum packaging - Anti-static packaging - Shockproof foam
- The terms here are for reference only, the actual terms are subject to the sales quotation. - Please confirm product specifications when ordering. - MOQ refers to the minimum order quantity required to purchase each part. - If you have special ordering instructions, please indicate them on the ordering page. - Inspection (PSI) will be performed prior to shipment.
- - Income Quality Control (IQC), 1000+ qualified dealers. - Chips are tested by authoritative organizations to ensure the quality, authenticity and safety of your device. - Decapsulation control - X-ray control - XRF inspection - Electrical testing - Surface testing -Digital components warehouse, covering an area of 800 square meters, with constant temperature and humidity
