MBR760 - Taiwan Semiconductor
Manufacturer:
Taiwan Semiconductor
ManyChip's Part#:
MC16446044
Category:
Schottky Diode
RoHS:
Lead free / RoHS Compliant
Datasheet:
Datasheet 3D Model
Description:
TAIWAN SEMICONDUCTOR MBR760 Small Signal Schottky Diode, Single, 60V, 7.5A, 750mV, 150A, 150℃
Stock Locations:
Availability:
1,582 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.76

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MBR760 is a Schottky Diode with moulded plastic body and pure tin-plated lead free terminals. It features high current capability, low forward voltage drop and high surge capability. It can be use in low voltage, high frequency inverters, freewheeling and polarity protection applications.
Metal silicon junction, majority carrier conduction
Low power loss, high efficiency
Guard ring for overvoltage protection
260°C/10seconds High temperature soldering guaranteed, 0.25" from case

Show

MBR760 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	TO-220
Load Current	7.5 A
Number of Positions	2 Position
Forward Current	7.5 A
Max Forward Surge Current (Ifsm)	150 A
Maximum Forward Voltage (Max)	750 mV
Operating Temperature (Max)	150 ℃
	Show
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
REACH SVHC Compliance Edition	2015/12/17
