MC33063ADRJR - TI
Manufacturer:
TI
ManyChip's Part#:
MC1437204
Category:
DC to DC Converter
Package:
WDFN-8
Datasheet:
Datasheet 3D Model
Description:
Conv DC-DC 3V to 40V Inv/Step Up/Step Down Single-Out 1.25V to 40V 1.5A 8Pin WSON EP T/R
Stock Locations:
Availability:
1,170 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.41

Updated at 03/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MC33063ADRJR is a Switching Regulator for use with cable solutions. The easy-to-use IC containing all the primary circuitry needed for building simple DC-to-DC converters. This device primarily consists of an internal temperature-compensated reference, a comparator, an oscillator, a PWM controller with active current limiting, a driver and a high-current output switch. Thus, the device requires minimal external components to build converters in the boost, buck and inverting topologies.
Adjustable output voltage
Short-circuit current limiting
Low standby current
2% Precision internal reference
Green product and no Sb/Br

Show

MC33063ADRJR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	WDFN-8
Number of Outputs	1 Output
Output Voltage	1.25V ~ 40V
Output Current	1.5 A
Number of Positions	8 Position
Quiescent Current	4.00 mA
Number of Regulated Outputs	1 Output
Switching Frequency	100 kHz
Input Voltage (Max)	40 V
Input Voltage (Min)	3 V
Output Voltage (Max)	40 V
Output Voltage (Min)	1.25 V
Output Current (Max)	1.5 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3 V
Input Voltage	3V ~ 40V
	Show
Size-Length	4.1 mm
Size-Width	4.1 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
