MC33262PG - ON Semiconductor
Manufacturer:
ON Semiconductor
ManyChip's Part#:
MC4078596
Category:
Power Management IC
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
ON SEMICONDUCTOR MC33262PG PFC Controller IC, Internal Startup Timer, 12V to 28V & 6.5mA Supply, 12V Lockout, 50kHz, SOIC-8
Stock Locations:
Availability:
53 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.92

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MC33262PG is an active Power Factor Controller specifically designed for use as a pre-converter in electronic ballast and in off-line power converter applications. This integrated circuit features an internal start-up timer for stand-alone applications, a one quadrant multiplier for near unity power factor and zero current detector to ensure critical conduction operation, trans-conductance error amplifier and quick-start circuit for enhanced start-up, trimmed internal band gap reference, current sensing comparator and a totem pole output ideally suited for driving a power MOSFET. Also includes protective features consisting of an overvoltage comparator to eliminate runaway output voltage due to load removal, input under-voltage lockout with hysteresis, Cycle-by-cycle current limiting and multiplier output clamp that limits maximum peak switch current, an RS latch for single pulse metering and a drive output high state clamp for MOSFET gate protection.
Over-voltage comparator eliminates runaway output voltage
Internal start-up timer
One quadrant multiplier
Zero current detectors
Trimmed 2% internal band gap reference
Totem pole output with high state clamp
Under-voltage lockout with 6V of hysteresis
-40 to 105°C Extended operating temperature range

Show

MC33262PG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Frequency	50 kHz
Supply Voltage (DC)	12.0V (min)
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Output Voltage	18 V
Number of Positions	8 Position
Power Dissipation	800 mW
Topology	Step-Up
Thermal Resistance	100 ℃/W
Output Current (Max)	500 mA
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	12V ~ 28V
Supply Voltage (Max)	28 V
Supply Voltage (Min)	12 V
	Show
Size-Length	10.16 mm
Size-Width	6.6 mm
Size-Height	3.44 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
