Description

This Relay Driver is intended to replace an array of three to six discrete components with an integrated SMT part. It can be used to switch 3 to 6 Vdc inductive loads such as relays, solenoids, incandescent lamps and small DC motors without the need of a free-wheeling diode.
Features
---
|
Provides a Robust Driver Interface between D.C. Relay Coil and Sensitive Logic Circuits
Optimized to Switch Relays from a 3 V to 5 V Rail
Capable of Driving Relay Coils Rated up to 2.5 W at 5 V
Features Low Input Drive Current and Good Back-to-Front Transient Isolation
Internal Zener Eliminates Need for Free-Wheeling Diode
Internal Zener Clamp Routes Induced Current to Ground for Quieter System Operation
Guaranteed Off State with no Input Connection
Supports Large Systems with Minimal Off-State Leakage
ESD Resistant in Accordance with the Class 1C Human Body Model
Low Sat Voltage Reduces System Current Drain by Allowing Use of Higher Resistance Relay Coils

Show

MDC3105DMT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SC-74
Supply Voltage (DC)	6.00V (max)
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Output Current	400 mA
Number of Positions	6 Position
Power Dissipation	380 mW
Output Current (Max)	500 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	380 mW
Supply Voltage	6 V
Supply Voltage (Max)	6 V
Supply Voltage (Min)	3 V
Input Voltage	6 V
	Show
Size-Length	3.1 mm
Size-Width	1.7 mm
Size-Height	1 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
