Image is for your reference only,please check specifications for details

MEE1S0303SC - muRata
Manufacturer:
muRata
ManyChip's Part#:
MC30849257
Category:
DC to DC Converter, DC/DC Converter
Package:
SIP-4
Datasheet:
Datasheet 3D Model
Description:
MURATA POWER SOLUTIONS MEE1S0303SC Isolated Board Mount DC-DC Converter, SIP, Fixed, Through Hole, 1W, 3.3V, 303mA
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The MEE1 series isolated single-output PCB-mounting DC/DC Converter with free air convection cooling. The device is more efficient and offers improved regulation performance for applications where a wide output voltage variation cannot be tolerated. This is ideally suited for providing local supplies on control system boards with the added benefit of 1kVDC galvanic isolation to reduce switching noise.
Operation to zero load
1kVDC Isolation hi pot test
Efficiency up to 87% typical

Show

MEE1S0303SC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	SIP-4
Power Rating	1 W
Number of Outputs	1 Output
Input Voltage (DC)	3.30 V
Output Voltage	3.3 V
Output Current	0.303 A
Output Power	1 W
Isolation Voltage	1 kV
Input Voltage (Max)	3.63 V
Input Voltage (Min)	2.97 V
Input Voltage (DC Max)	3.63 V
Input Voltage (DC Min)	2.97 v
Output Current (Max)	303 mA
Input Power (Max)	1 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	2.97V ~ 3.63V
	Show
Size-Length	11.48 mm
Size-Width	6 mm
Size-Height	10 mm
Weight	1.3 g
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
