Description

The MJE253G is a -100V Silicon PNP Complementary Plastic Power Transistor designed for low power audio amplifier as well as low current and high speed switching applications.
High collector-emitter sustaining voltage
High DC current gain
Low collector emitter saturation voltage
High current gain bandwidth
Annular construction for low leakages

Show

MJE253G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-126-3
Frequency	40 MHz
Voltage Rating (DC)	-100 V
Current Rating	-4.00 A
Halogen Free Status	Halogen Free
Number of Positions	3 Position
Polarity	PNP
Power Dissipation	15 W
Breakdown Voltage (Collector to Emitter)	100 V
Thermal Resistance	8.34℃/W (RθJC)
Continuous Collector Current	4A
hFE Min	40 @200mA, 1V
hFE Max	180
Input Power (Max)	1.5 W
DC Current Gain (hFE)	40
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-65 ℃
Power Dissipation (Max)	15000 mW
	Show
Size-Length	7.74 mm
Size-Width	2.66 mm
Size-Height	11.04 mm
Material	Silicon
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99
