Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 2 Pin |
Case/Package | SOD-123-2 |
Voltage Rating (DC) | 100 V |
Current Rating | 200 A |
Capacitance | 4.00 pF |
Halogen Free Status | Halogen Free |
Output Current | ≤200 mA |
Number of Positions | 2 Position |
Forward Voltage | 1 V |
Polarity | Standard |
Power Dissipation | 425 mW |
Thermal Resistance | 290℃/W (RθJA) |
Reverse recovery time | 4 ns |
Forward Current | 200 mA |
Max Forward Surge Current (Ifsm) | 2 A |
Maximum Forward Voltage (Max) | 1 V |
Forward Current (Max) | 200 mA |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Junction Temperature (Max) | 150 ℃ |
Power Dissipation (Max) | 425 mW |
Show | |
Size-Length | 2.69 mm |
Size-Width | 1.6 mm |
Size-Height | 1.12 mm |
Operating Temperature | -55℃ ~ 150℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
ECCN Code | EAR99 |
HK STC License | NLR |
