Description

Ensure minimum energy usage by avoiding AC power outlets and instead using ON Semiconductor"s NCP1081DEG power over Ethernet controller. Use this part at voltages between 0 V and 57 V. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This POE controller"s maximum duty cycle is 80(Typ) %. This POE controller has an operating temperature range of -40 °C to 85 °C.

Show

NCP1081DEG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	TSSOP-20
Frequency	500 kHz
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Input Voltage (DC)	57.0 V
Output Voltage	3.3V ~ 9V
Output Current	1.1 A
Supply Current	1100 mA
Number of Channels	1 Channel
Number of Positions	20 Position
Rise Time	50 ns
Switching Frequency	500 kHz
Topology	Flyback
Duty Cycle	80 %
Input Voltage (Max)	57 V
Input Voltage (Min)	0 V
Input Power (Max)	40 W
Input Power (Max)	40 W
Maximum Duty Cycle	80 %
Fall Time	50 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	0V ~ 57V
Input Voltage	57 V
	Show
Size-Length	6.6 mm
Size-Width	4.5 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	3A991
