Description

The NL17SZ125DTT1G is a non-inverting high performance Buffer with 3-state outputs an operating from a 1.65 to 5.5V supply. It features near zero static supply current substantially reduces system power requirements and LVTTL compatible - interface capability with 5V TTL logic with VCC = 3V.
Overvoltage tolerant inputs and outputs
LVCMOS Compatible
24mA Balanced output sink and source capability
3-state OE input is active-low
Replacement for NC7SZ125
Chip complexity = 36 FETs
Designed for 1.65 to 5.5V VCC operation

Show

NL17SZ125DTT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	TSOT-23-5
Supply Voltage (DC)	1.65V (min)
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Number of Channels	1 Channel
Number of Positions	5 Position
Power Dissipation	150 mW
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	150 mW
Supply Voltage	1.65V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	1.65 V
	Show
Size-Length	3 mm
Size-Width	1.5 mm
Size-Height	1.05 mm
Operating Temperature	-55℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
