**NL27W Series, ON Semiconductor**
CMOS Logic gates with LVTTL compatible inputs and outputs, offering higher speed and greater drive capability than 74LCX devices

Show

NL27WZ04DFT2G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SC-70-6
Supply Voltage (DC)	1.80 V
Operating Voltage	1.65V ~ 5.5V
Capacitance	2.5 pF
Halogen Free Status	Halogen Free
Output Current	32 mA
Supply Current	10 μA
Number of Circuits	2 Circuit
Number of Positions	6 Position
Power Dissipation	200 mW
Quiescent Current	1 µA
Number of Gates	2 Gate
Number of Inputs	1 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	1.65V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	1.65 V
	Show
Size-Length	2.2 mm
Size-Height	1 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
