Description

The NTHD4508NT1G is a ChipFET™ dual N-channel Power MOSFET designed for battery and low side switching in portable equipment such as MP3 players, cell phones, DSCs and PDAs. It is suitable for DC-to-DC buck/boost converter and level shifting applications.
Low RDS (ON) and fast switching
Excellent thermal capabilities where heat transfer is required

Show

NTHD4508NT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SMD-8
Voltage Rating (DC)	20.0 V
Current Rating	3.10 A
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.06 Ω
Polarity	N-Channel, Dual N-Channel
Power Dissipation	2.1 W
Threshold Voltage	1.2 V
Drain to Source Voltage (Vds)	20 V
Breakdown Voltage (Drain to Source)	20.0 V
Breakdown Voltage (Gate to Source)	±12.0 V
Continuous Drain Current (Ids)	4.10 A, 4.10 mA
Rise Time	15 ns
Input Capacitance (Ciss)	180pF @10V(Vds)
Input Power (Max)	1.13 W
Fall Time	3 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2.1 W
	Show
Size-Length	3.1 mm
Size-Width	1.7 mm
Size-Height	1.1 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
