Description

* FETKY™ Configuration with MOSFET plus Low Vf Schottky Diode * µCool™ Package Provides Exposed Drain Pad for Excellent Thermal Conduction * 2x2 mm Footprint Same as SC-88 Package Design * Indepedent Pinout Provides Circuit Design Flexibility * Low Profile ( * High Current Schottky Diode:2 A Current Rating * This is a Pb-Free Device

Show

NTLJF3117PT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	WDFN-6
Drain to Source Resistance (on) (Rds)	100 mΩ
Polarity	P-Channel
Power Dissipation	1.5 W
Drain to Source Voltage (Vds)	20 V
Continuous Drain Current (Ids)	4.10 A, -3.30 A
Input Capacitance (Ciss)	531pF @10V(Vds)
Input Power (Max)	710 mW
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	710mW (Ta)
	Show
Size-Length	2 mm
Size-Width	2 mm
Size-Height	0.75 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99
