Description
- N-Channel 100V 11A (Ta), 55A (Tc) 3.8W (Ta), 94W (Tc) Surface Mount 5-DFN (5x6) (8-SOFL)
NVMFS6B14NLT1G Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | DFN-5 |
| Number of Positions | 5 Position |
| Drain to Source Resistance (on) (Rds) | 0.0105 Ω |
| Polarity | N-Channel |
| Power Dissipation | 94 W |
| Threshold Voltage | 3 V |
| Drain to Source Voltage (Vds) | 100 V |
| Continuous Drain Current (Ids) | 11A |
| Rise Time | 67.6 ns |
| Input Capacitance (Ciss) | 1680pF @25V(Vds) |
| Fall Time | 7.2 ns |
| Operating Temperature (Max) | 175 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 94 W |
| Show | |
| Size-Length | 5.1 mm |
| Size-Width | 6.1 mm |
| Size-Height | 1.05 mm |
| Operating Temperature | -55℃ ~ 175℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | Compliant with Exemption |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2016/06/20 |
| ECCN Code | EAR99 |
